#### PCO-6131 | 125A Output Current Pulsed / CW Laser Diode Driver Module





The EVO Series delivers exceptional precision, rapid control, and user-friendly operation in a compact, high-power-density package—ideal for demanding high-voltage applications.

- Power ratings: 2 kW or 3 kW
- Voltage classes: 0–1.5 kV DC, 0–5 kV DC, 0–10 kV DC (up to 20 kV in select configs)
- Currents: from 0.2 A to 2 A (model-dependent)
- Compact form factor: only 2U rack height (benchtop or 19″ rack with adapter)
- Fully digital regulation via microcontroller + FPGA for fast signal processing and adaptable load response
- Electrically reversible polarity (positive or negative HV output)
- User-friendly operating system with intuitive controls
- High power density and quick, precise control without compromising speed or accuracy

Contact our team to discuss custom specifications for your optimal high-voltage supply solution.

Learn more on this [Youtube Video](https://www.youtube.com/watch?v=7sHaxpXyt4k).









##### [Features](#features-section)







##### [Specifications](#specifications-section)







##### [Tech Resources](#technical-resources-section)







##### [Media](#media-section)







##### [Downloable Resources](#downloadable-section)







##### [Price List](#pricelist-section)











#### Overview









##### Applications





- Driving high power laser diodes, bars and arrays in pulsed, QCW or CW modes.







##### Features





- 1 A To 125 A Output Current
- Less than 100 ns to DC Variable Pulse Width
- 20 V Maximum Output Voltage
- 2.5 kW Maximum Average Output Power
- User-Adjustable Variable Rise Time
- Repetition Frequency Single-Shot to 500 kHz











#### Specifications









**Compliance Voltage**







20V











**Max Current Amplitude**







125A











**Rise/Fall Time**







30ns











**Max Frequency**







500 kHz











**Pulse Engine (Trigger)**







External











**Remote Control**







N/A











**Form Factor**







Module











**Cooling**







Ambient Air











**Dimensions (in)**







12x10x10











**Weight (lbs)**







10











#### Technical Resources









  [ Press Room – BNC’S PCO-6131: The Ultimate Solution For Driving High-Power Laser Diodes](https://www.berkeleynucleonics.com/download/27957/?tmstv=1782227259)
 [ PCO-6131 Datasheet](https://www.berkeleynucleonics.com/download/27960/?tmstv=1782227259)
